Product Title: | IP65 Waterproof LED panel 595595 |
Product Features 1: | Suitable for humid areas, vapor area, washed area |
Product Features 2: | We only use good quality core materials,include LM80 LED, certified LED driver, thick copper PCB, PMMA LGP, certified wires. |
Product Features 3: | We PMMA as our LGP, the panel don't be yellow within 5 years. |
Product Features 4: | The product structure is strong and thick, and the structure design ensures the waterproof function. |
Product Features 5: | With IP65 waterproof testing report. |
Product Parameters | ||||||||
No | Products Sereis | Size（MM） | Watt (W ) | Input Volt (Vac) | RA | lm/W | Lumen (LM) | UGR |
1 | W3 | 595*595*14 | 40 | 200-240 | >80 | 120 | 4800 LM | UGR<19 |
2 | W3 | 595*595*14 | 36 | 200-240 | >80 | 120 | 4320 LM | UGR<19 |
Application reference (the following parameters are only for selection reference based on typical values. For different project requirements, you can contact the factory for separate lighting design for the project. The design fee will be prepaid before the order is placed and refunded after the order is placed) | ||||||||
No | Products Sereis | Size （MM） | Watt (W ) | Typical Lumen | Height of Space(M) | LUX | Lighting Power Density(W/m²) | Applying Area (m²) |
1 | W3 | 595*595*14 | 40W | 4800LM | 3M | 300 | 3.05 | 13.1 m² (typical) |
2 | W3 | 595*595*14 | 36W | 4200LM | 3M | 300 | 2.92 | 12.3 m² (typical) |
