Back-Lit Energy-Saving LED Panel Light T-BAR Keel Type (Used Abroad First)

595595P2-W xxKxx

Product Title:

High efficiency backlite LED panel 595595

Product Features 1:

Reduce power density to save electricity costs
The higher the light efficiency, the lower the power density, the more energy saving.

Product Features 2:

The light is uniform and not dazzling

Product Features 3:

We only use good quality core materials,include LM80 LED, certified LED driver, thick copper PCB, certified wires.

Product Parameters

No

Products Sereis

Size(MM)

Watt        (W )

Input Volt    (Vac)

RA

lm/W

Lumen (LM)

1

P2

595*595*35

35W

200-240

>80

140

4900 LM

2

P2

595*595*35

30W

200-240

>80

140

4200 LM

3

P2

595*595*35

27W

200-240

>80

140

3800 LM

Application reference (the following parameters are only for selection reference based on typical values. For different project requirements, you can contact the factory for separate lighting design for the project. The design fee will be prepaid before the order is placed and refunded after the order is placed)

No

Products Sereis

Size(MM)

Watt        (W )

Typical Lumen

Height of Space(M)

LUX

Lighting Power Density(W/m²)

Applying Area (m²)

1

F2

595*595*9.5

35W

4900 LM

3M

300

3.05

13.1 m² (typical)

2

F2

595*595*9.5

30W

4200 LM

3M

300

2.93

12.3 m² (typical)

3

F2

595*595*9.5

27W

3800 LM

3M

300

2.88

11.1 m² (typical)

×
